T" TYPE SPINNER HANGER MACHINE

Production lines based upon Continuous production systems are very suitable for incorporating T" Type Spinner Hanger Shot Blasting Machines. These machines are designed to shot blast large forging and fabricated components such as axles, boom, bucket and stick for back hoe of loader excavators.

Components are mounted on the hooks and simultaneously one job is getting processed in the blasting chamber. Additional heavy duty hanging liners are also provided at the blasting hot zone. The blasting chamber is lined completely with wear resistant manganese liners The surface finishing of the jobs are ensured by proper rotation and simultaneously oscillation of the job hook through a suitable spinner drive arrangement.

APPLICATION: Shot Blasting, Cleaning, Corrosion Removal, Rust and Heat Scale Removal, Surface Texturing, Paint Preparation

MACHINE GENERAL SPECS

• ENVELOPE SIZE (max) – Ø800mm X 1100mm  Ø1000mm X 1200mm  Ø1000mm X 2100mm
• HANGER LOADING WEIGHT – Max 300 Kgs Max 500 Kgs  Max 1000 Kgs
• NO. OF BLASTING WHEELS – 2 - 4
• NO. OF HANGERS – 2
• DELIVERY – 12 WEEKS +

KEY ADVANTAGES

• HIGHLY FLEXIBLE IN SHOT BLASTING DIFFERENT COMPONENTS
• LOADING AND UNLOADING CAN BE DONE CONTINEOUSLY WHILE THE SHOT BLASTING PROCESS IS ON.
• SELF CONTAINED MACHINE
• HIGH PROCESS REPEATABILITY
• ENERGY SAVING MODE

FEATURES

• FULL PLC CONTROL
• TROLLEY
• MOTORIZED BEAM TYPE CONVEYOR FOR JOB MOVEMENT

OPTIONAL FEATURES

• PILZ SAFETY RELAY
• TEMPERATURE SENSOR WITH FIRE DOSING FACILITY
• INDIGENOUSLY DEVELOPED MEDIA FLOW CONTROLLER
• CONTROL OF BLASTING WHEEL RPM
• MACHINE CAN BE MADE PITLESS AS WELL AS PITLESS TYPE
• HEAVY HOOK LOAD UPTO 1.5 TONS
• EXTENDED HOPPER WITH SCREW CONVEYOR FOR SPILLED MEDIA COLLECTION AND CIRCULATION
